Safety Glass Impact Test Device
Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device
Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device Safety Glass Impact Test Device

Safety Glass Impact Test Device

420-980 USD ($)/Set

Product Details:

  • Weight 10 Kilograms (kg)
  • Usage The purpose of this test is to verify the compliance of glazing with the asking relating to the limitation of injury in the event of impact of the head against the windscreen, laminated glass and glazing of glass-plastic and rigid plastic other than windscreens, together with The double-glazed units used in the side windows.
  • Color Black
  • Application The purpose of this test is to verify the compliance of glazing with the asking relating to the limitation of injury in the event of impact of the head against the windscreen, laminated glass and glazing of glass-plastic and rigid plastic other than windscreens, together with The double-glazed units used in the side windows.
  • Dimension(L*W*H) 500*932 Millimeter (mm)
  • Operate Method Manual control
  • Classification A
  • Supply Ability : 100 Set Per Month
  • Click to view more
X

Price And Quantity

  • 1 Set
  • 420.00 - 980.00 USD ($)/Set
  • 420-980 USD ($)/Set

Product Specifications

  • 500*932 Millimeter (mm)
  • Manual control
  • A
  • 10 Kilograms (kg)
  • The purpose of this test is to verify the compliance of glazing with the asking relating to the limitation of injury in the event of impact of the head against the windscreen, laminated glass and glazing of glass-plastic and rigid plastic other than windscreens, together with The double-glazed units used in the side windows.
  • 10 Kilograms (kg)
  • The purpose of this test is to verify the compliance of glazing with the asking relating to the limitation of injury in the event of impact of the head against the windscreen, laminated glass and glazing of glass-plastic and rigid plastic other than windscreens, together with The double-glazed units used in the side windows.
  • Black

Trade Information

  • Tianjin
  • Telegraphic Transfer (T/T)
  • 100 Set Per Month
  • 30 Days
  • Contact us for information regarding our sample policy
  • Plywood case (Meet import and export requirements)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

Related Standard:

ISO 3537 Roadvehicles –Safety glazing materials — Mechanical tests – Clause 10 Head-formtest

Principle:Assessment of the minimum strength and cohesion of the safety glazing materialunder impact from a blunt, bulky object. If required, tests can be performed onwhole windscreens.

Application:

The purpose ofthis test is to verify the compliance of glazing with the asking relating tothe limitation of injury in the event of impact of the head against thewindscreen, laminated glass and glazing of glass-plastic and rigid plasticother than windscreens, together with The double-glazed units used in the sidewindows.

Technical Data:

Head-formWeight: 10kg

Head-form Size:500mm*932mm

Impact height:< 1.5m

Samples size:1100mm*500mmw

Felt hat:90g/89mm Thickness:5mm

Frame size:1376mm*670mm*320mm

Apparatus:

Head-form weight,with a spherical or semi-spherical head made of laminated hard wood coveredwith replaceable felt and without a cross-beam made of wood. Between thespherical part and the cross-beam, there is a neck-shaped intermediate pieceand on the other side of the cross-beam, a mouning rod.

The total massof the apparatus shall be 10 kg±0.2 kg

Supporting fixture:

for testing flattest piece, the fixture is composed of two steel frames, with machined edges,50mm wide, fitting one over the other and faced with rubber gaskets 3mm±0,5mmthick and 15mm±1mm wide, of hardness 70 IRHD.

The upper frameis pressed against the lower frame by at least eight bolts. The support shallrest on a rigid stand with a sheet of rubber, of hardness 70 IRHD and 3mm±0,5mmthick, placed in between.
